MPG A1000G PCIE5

Drive Bays
CPU Cooler Support
Efficiency
Radiator Size Support
Case Form Factor
Fan Size
Dimensions (DxWxH)
Modular
Dimension
PFC Type
Fan Bearing
Product Name
PSU Form Factor
Power Watt
Power Excursion
Input Voltage
Protection
ATX (24 pin)
Input Frequency
EPS (4+4 pin)
PCI-E 5.0 (16 pin)
PCI-E (6+2 pin)
SATA (15 pin)
MOLEX (4 pin)
FDD (4 pin)

Drive Bays

2 x 3.5" (compatible with 2.5" ) + 4 x 2.5"

CPU Cooler Support

Max 170mm / 6.69 inch

Efficiency

80 PLUS Gold (up to 90%)

Radiator Size Support

Front: 120 / 140 / 240 / 280 / 360 mm
Top: 120 / 140 / 240 / 280 / 360 mm
Rear: 120 / 140 mm
Side: 120 / 240 / 360 mm

Case Form Factor

Mid-Tower

Fan Size

135 mm

Dimensions (DxWxH)

585x 257 x 537 mm / 23.03 x 10.12 x 21.14 inches

Modular

Yes (fully modular)

Dimension

150 x 150 x 86 mm

PFC Type

Active PFC

Fan Bearing

Fluid Dynamic Bearing

Product Name

MPG A1000G PCIE5

PSU Form Factor

ATX

Power Watt

1000W

Power Excursion

2000W (*up to 200% of the PSU's rated power for 100μs)

Input Voltage

100~240 VAC

Protection

OCP / OVP / OPP / OTP / SCP / UVP

ATX (24 pin)

Input Frequency

50~60 Hz

EPS (4+4 pin)

PCI-E 5.0 (16 pin)

1 (600W)

PCI-E (6+2 pin)

SATA (15 pin)

MOLEX (4 pin)

FDD (4 pin)
